Galois Fields in AES — Reference
Mathematical reference for the Galois Field arithmetic that underpins AES encryption. Covers GF(2⁸) structure, polynomial representation, the AES irreducible polynomial, and the Extended Euclidean Algorithm for computing multiplicative inverses.
What is GF(2⁸)?
AES operates over GF(2⁸) — a Galois Field with 256 elements. Every element in GF(2⁸) is represented as a polynomial of degree ≤ 7 with coefficients in GF(2) (i.e., each coefficient is either 0 or 1).
Polynomial Representation
An element looks like:
a₇x⁷ + a₆x⁶ + a₅x⁵ + a₄x⁴ + a₃x³ + a₂x² + a₁x + a₀
where each aᵢ ∈ {0, 1}.
Each polynomial maps exactly to one 8-bit byte, with each bit representing a coefficient. This alignment with computer memory is why GF(2⁸) was chosen for AES.
Why GF(2⁸)?
| Property | Benefit |
|---|---|
| Byte alignment | Each field element = 1 byte — natural fit for CPU architecture |
| Closed arithmetic | Addition, subtraction, multiplication, and division always stay within the field |
| Finite and deterministic | Results are always predictable — essential for a cryptographic standard |
The Irreducible Polynomial
AES uses the following irreducible polynomial as the modulus for all multiplication:
P(x) = x⁸ + x⁴ + x³ + x + 1
Why irreducible? Just as prime numbers are the foundation of modular integer arithmetic, irreducible polynomials are the foundation of Galois Field arithmetic. Multiplying two polynomials can produce a result of degree > 7, which falls outside GF(2⁸). The irreducible polynomial is used to reduce that result back into the field via modulo operation — analogous to clock arithmetic (e.g., 10 + 5 = 3 on a 12-hour clock).
Extended Euclidean Algorithm — Finding Inverses in GF(2ᵐ)
The MixColumns step in AES requires the multiplicative inverse of field elements. The Extended Euclidean Algorithm computes these efficiently.
Goal
Given element A(x) in GF(2ᵐ) and irreducible polynomial P(x), find A⁻¹(x) such that:
A⁻¹(x) · A(x) ≡ 1 (mod P(x))
Algorithm
The Extended Euclidean Algorithm iteratively applies polynomial division, tracking intermediate values to find polynomials U(x) and V(x) satisfying:
U(x) · A(x) + V(x) · P(x) = GCD(A(x), P(x))
Since A(x) and P(x) are both elements of a Galois Field built from an irreducible polynomial, their GCD is always 1:
U(x) · A(x) + V(x) · P(x) = 1
Taking this equation modulo P(x):
U(x) · A(x) ≡ 1 (mod P(x))
Therefore U(x) is the multiplicative inverse of A(x).
Worked Example — GF(2³), P(x) = x³ + x + 1
Find the inverse of A(x) = x² + 1.
Initialization
| Variable | Value |
|---|---|
| r₀ | x³ + x + 1 (= P(x)) |
| r₁ | x² + 1 (= A(x)) |
| s₀ | 1 |
| s₁ | 0 |
| t₀ | 0 |
| t₁ | 1 |
Iteration 1 — Divide r₀ by r₁
(x³ + x + 1) ÷ (x² + 1) → quotient = x, remainder = x + 1
r₂ = x + 1
s₂ = s₀ − x · s₁ = 1 − x · 0 = 1
t₂ = t₀ − x · t₁ = 0 − x · 1 = −x ≡ x (in GF(2), −1 = 1)
Iteration 2 — Divide r₁ by r₂
(x² + 1) ÷ (x + 1) → quotient = x + 1, remainder = 0
Remainder is 0 — algorithm terminates.
Result
The last non-zero remainder is r₂ = x + 1, confirming GCD = 1 (as expected).
The inverse is:
A⁻¹(x) = t₂ = x
Verification:
x · (x² + 1) = x³ + x
x³ + x mod (x³ + x + 1) = (x³ + x) − (x³ + x + 1) = 1 ✓
Connection to AES
The operations described here are used directly in the SubBytes and MixColumns steps of AES:
| AES Step | GF(2⁸) Operation |
|---|---|
| SubBytes (S-box) | Compute multiplicative inverse of each byte in GF(2⁸), then apply affine transformation |
| MixColumns | Multiply each column's bytes by a fixed polynomial over GF(2⁸) |
| AddRoundKey | XOR — equivalent to polynomial addition in GF(2⁸) |
The security of AES relies on the non-linearity introduced by S-box inversion in GF(2⁸), making it resistant to linear and differential cryptanalysis.
